RX-880B
Automatic Sleeve Sealer Shrink Packing Machine（Cylinder shape products packaging）
Summary：RX-750B/ RX-880B automatic sleeve sealing shrink tunnel machine (straight line feeding conveyor) is designed for packing cylinder shape products.
Machine conveyor can be customized according to different shape and dimension cyliner products.
Available connecting machine:
1. Automatic labelling machine
2. Cartoning sealing machine
1.RX-750/880B adopts advance techology which can ensure the machine working stable.
2.Adopt "Siemens" and "PLC" programmable controller to realize the integration of machinery, electricity and gas
3. Machine is available adjusting for different sizes products.
4.The worm gear reducer is adopted to ensure the feeding conveyor and film feeding working stable without jitter.
5.Specially designed sealing knife is adopted, and the sealing line is firm, non cracking and not easy to stick to the knife.
8.Phorocell is available for printed film.
| Model | RX-750B | RX-880B |
| Power supply | 380V/50-60Hz | |
| Maximum packing size | 380(L)*200(W)*200(H)mm |
500(L)*400(W)*320(H)mm |
| Packing speed | 8-20packs/ Minute | |
| Film type | Single layer PE film | |
| Maximum film size |
500mm(Width)×280mm（Outer Diameter） |
800mm(Width)×280mm（Outer Diameter） |
| Power consumption | 16KW |
20.5KW |
| Tunnel oven dimension |
1500mm(L), 500(W)*300(H)mm |
1500mm(L), 600(W)*400(H)mm |
| Tunnel conveyor speed |
Variable，30M/ Minute |
|
| Working plate height |
850-950mm |
|
| Air pressure |
≤0.5MPa(5 bar) |
|
| Sealing knife |
Special
durable alloyed sealing knife with anti-stick Teflon coats |
|
| Operating panel | Delta colorful touch screen and PLC, Omron temperature controller | |
| Machine material | Carbon steel/ Stainless |
Carbon steel/ Stainless steel |
| Machine wieght | 700KG | 900KG |
| The above parameters for reference only, we can provide different customized solutions for various products dimensions | ||
